6935364083571 TP-Link EAP225-Outdoor Omada AC1200 1200Mbps Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point Passive PoE Weatherproof High Gain Long Range Ant.

6935364083571 TP-Link EAP225-Outdoor Omada AC1200 1200Mbps Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point Passive PoE Weatherproof High Gain Long Range Ant.

(0 review)

Product Code: 6935364083571

TP-Link EAP225-Outdoor Omada AC1200 1200Mbps Wireless MU-MIMO Gigabit Indoor/Outdoor Access Point Passive PoE Weatherproof High Gain Long Range antena
Durable, weatherproof enclosure for outdoor Wi-Fi applications
Up to 1200Mbps with 2×2 MIMO technology
High transmission power and high gain antennas provide a long-range coverage area
Free Omada Controller software enables administrators easily manage hundreds of EAPs
Captive portal provides a convenient method for guest authentication
Facebook Wi-Fi and SMS anthentication help to boost your business
802.3af/Passive PoE (PoE Adapter Included) compatible and simple mounting design allow for flexible deployment and convenient installation
HARDWARE FEATURES
Interface Gigabit Ethernet (RJ-45)Port*1(Support 802.3af PoE and Passive PoE)
Button Reset
Power Supply 802.3af PoE and 24 Passive PoE(PoE Adapter Included)
Power Consumption 10.5W
Antenna 2.4GHz: 2 * 3dBi, 5GHz: 2 * 4dBi
Dimensions ( W x D x H ) 8.5 × 1.8 × 1.1in. (215 × 46 × 27 mm)
Mounting Pole/Wall Mounting (Kits included)
Hardware Watch Dog Yes
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/b/g/n/ac
Frequency 2.4GHz, 5GHz
Signal Rate 802.11ac: 5G:6.5 Mbps to 867Mbps(MCS0-MCS9,NSS = 1 to 2 VHT20/40/80) 2.4G:78Mbps to 300Mbps (MCS8-MCS9 VHT20/40, NSS=1 to 3)
802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, VHT 20/40)
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 5.5, 11Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Functions Multiple SSIDs（Up to 16 SSIDs, 8 for each band）
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control （Adjust Transmit Power on dBm）
QoS(WMM)
MU-MIMO
Airtime Fairness
Beamforming
Band Steering
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Det

$ 129.00 $ 129.00 (Tax excluded)

  • Brand
  • Manufacturer
Add to cart
Add to wishlist
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

TP-Link Omada EAP225-Outdoor, 2.4 GHz, 5 GHz, 1200 Mbit/s, 802.1x RADIUS, 10,100,1000 Mbit/s

TP-Link Omada EAP225-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1200 Mbit/s. Security algorithms: 802.1x RADIUS. Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White

Features
2.4 GHzYes
5 GHzYes
6 GHzNo
Maximum data transfer rate1200
Maximum data transfer rate (2.4 GHz)300
Maximum data transfer rate (5 GHz)867
Ethernet LAN data rates10,100,1000
Frequency band2.4 - 5
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u
MIMOYes
MIMO typeMulti User MIMO
Wi-Fi Multimedia (WMM)/(WME)Yes
VLAN supportYes
Virtual LAN featuresVLAN mapping
Rate limitingYes
Band steeringYes
Airtime Fairness (ATF)Yes
Quality of Service (QoS) supportYes
BeamFormingYes
Transmitting power (CE)27
Transmitting power (FCC)22
Security
Security algorithms802.1x RADIUS
MAC address filteringYes
Service Set Identifier (SSID) featuresMultiple SSIDs
Number of SSID supported16
Access Control List (ACL)Yes
Management features
Web-based managementYes
SyslogYes
Ports & interfaces
Ethernet LAN (RJ-45) ports1
Power
Power over Ethernet (PoE)Yes
Power over Ethernet (PoE) type supportedPassive PoE
Output voltage24
Power consumption (typical)10.5
Design
PlacementPole, Wall
Product colourWhite
International Protection (IP) codeIP65
Reset buttonYes
Antenna
Antenna typeExternal
Antenna direction typeOmni-directional
Antenna featuresDetachable antenna
Antennas quantity2
Antenna gain level (max)4
Performance
Compatible operating systemsMicrosoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Certificates
Compliance certificatesCE, Federal Communications Commission (FCC), RoHS
Weight & dimensions
Width215
Depth46
Height27
Packaging data
Package width140
Package depth270
Package height100
Package weight640
Packaging content
Quantity per pack1
AC adapter includedYes
Mounting kitYes
Quick start guideYes
Operational conditions
Operating relative humidity (H-H)10 - 90
Operating temperature (T-T)-30 - 70
Storage temperature (T-T)-40 - 70
Storage relative humidity (H-H)5 - 90
Sustainability
Sustainability complianceYes
Logistics data
Harmonized System (HS) code85176990

Specifications

Brand TP-Link
Manufacturer TP-Link
