TP-Link 5GHz 150Mbps 23dBi Outdoor CPE, 23 dBi, 5 GHz, IEEE 802.11a, IEEE 802.11n, 10/100Base-T(X), 23 dBi, 7°
TP-Link 5GHz 150Mbps 23dBi Outdoor CPE. Antenna gain level (max): 23 dBi, Frequency band: 5 GHz, Networking standards: IEEE 802.11a, IEEE 802.11n. Antenna type: Directional antenna, Product colour: White, Housing material: Plastic. Power source type: PoE, Input voltage: 16 - 27 V. Compliance certificates: RoHS, Certification: CE, FCC. Width: 233.4 mm, Depth: 170 mm, Height: 156 mm
| Performance | |
|---|---|
| Frequency band | 5 |
| Networking standards | IEEE 802.11a, IEEE 802.11n |
| Cabling technology | 10/100Base-T(X) |
| Gain | 23 |
| Horizontal beam width | 7 |
| Vertical beam width | 10 |
| Built-in processor | Yes |
| Processor model | Atheros MIPS 74Kc |
| Processor frequency | 560 |
| Internal memory | 64 |
| Internal memory type | DDR2 |
| Flash memory | 8 |
| Antenna gain level (max) | 23 |
| Features | |
| Antenna type | Directional antenna |
| Product colour | White |
| Housing material | Plastic |
| Protection features | Dust resistant, Water resistant |
| International Protection (IP) code | IP65 |
| Waterproof | Yes |
| Mounting | Pole |
| Power | |
| Power source type | PoE |
| Input voltage | 16 - 27 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, FCC |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 70 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 95 |
| Weight & dimensions | |
| Width | 233.4 |
| Depth | 170 |
| Height | 156 |
| Packaging data | |
| Package width | 328 |
| Package depth | 155 |
| Package height | 135 |
| Package weight | 1.42 |
| Packaging content | |
| Quantity per pack | 1 |
| Cables included | AC |
| Mounting kit | Yes |
| Quick installation guide | Yes |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85177100 |
Specifications
| Brand | TP-Link |
| Manufacturer | TP-Link |
