APC Smart-UPS On-Line, 1000VA/1000W, Tower, 230V, 6x C13 IEC outlets, SmartSlot, Extended runtime, W/O rail kit, Double-conversion (Online), 1 kVA, 1000 W, Sine, 220 V, 240 V
APC Smart-UPS On-Line, 1000VA/1000W, Tower, 230V, 6x C13 IEC outlets, SmartSlot, Extended runtime, W/O rail kit. UPS topology: Double-conversion (Online), Output power capacity: 1 kVA, Output power: 1000 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 12 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery voltage: 48 V, Typical backup time at full load: 8 min. Form factor: Rackmount/Tower, Product colour: Black, Rack capacity: 2U. Compliance certificates: CE, Certification: CE, EAC
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1 |
| Output power | 1000 |
| Waveform | Sine |
| Input operation voltage (min) | 220 |
| Input operation voltage (max) | 240 |
| Input frequency | 40/70 |
| Output operation voltage (min) | 50 |
| Output operation voltage (max) | 240 |
| Output frequency | 50/60 |
| Surge energy rating | 432 |
| Crest factor | 3:1 |
| ECO mode | Yes |
| Emergency Power Off (EPO) | Yes |
| Output voltage Total Harmonic Distortion (THD) | 2 |
| Noise level | 50 |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Battery replacement |
| Auto-restart | Yes |
| Ports & interfaces | |
| AC outlet types | C13 coupler |
| Power plug | C14 coupler |
| AC outlets quantity | 12 |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RJ-45 |
| Serial ports quantity | 1 |
| SmartSlot | Yes |
| SmartConnect port | No |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 48 |
| Typical backup time at full load | 8 |
| Typical backup time at half load | 21 |
| Battery life (max) | 5 |
| Battery recharge time | 3 |
| Hot-swap battery | Yes |
| Automatic battery test | Yes |
| Cold start | Yes |
| Design | |
| Form factor | Rackmount/Tower |
| Rack capacity | 2U |
| Cable length | 1.8 |
| Cooling type | Active |
| Built-in fan | Yes |
| Product colour | Black |
| Display type | LCD |
| LED indicators | Yes |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 50 |
| Operating relative humidity (H-H) | 0 - 95 |
| Operating altitude | 0 - 3048 |
| Non-operating altitude | 0 - 15240 |
| Certificates | |
| Compliance certificates | CE |
| Certification | CE, EAC |
| Packaging content | |
| Cables included | USB cable |
| Management card included | No |
| Quick installation guide | Yes |
| Sustainability | |
| Sustainability compliance | Yes |
| Sustainability certificates | Green Premium |
| Weight & dimensions | |
| Width | 85 |
| Depth | 505 |
| Height | 432 |
| Weight | 20.5 |
| Battery width | 59.4 |
| Battery depth | 74.9 |
| Battery height | 24.6 |
| Battery weight | 29.6 |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Total carbon footprint (kg of CO2e) | 1839.69 |
| Other features | |
| Nominal output voltage | 230 |
| Nominal input voltage | 230 |
Specifications
| Brand | APC |
