APC Smart-UPS On-Line, 2200VA, Rackmount 3U, 230V, 6x C13+2x C19 IEC, Network Card, Extended runtime, W/ rail kit, W/ Lithium-ion external battery, Double-conversion (Online), 2.2 kVA, 1980 W, Sine, 160 V, 275 V
APC Smart-UPS On-Line, 2200VA, Rackmount 3U, 230V, 6x C13+2x C19 IEC, Network Card, Extended runtime, W/ rail kit, W/ Lithium-ion external battery. UPS topology: Double-conversion (Online), Output power capacity: 2.2 kVA, Output power: 1980 W. AC outlet types: C13 coupler, C19 coupler, AC outlets quantity: 8 AC outlet(s). Battery technology: Lithium-Ion (Li-Ion), Battery voltage: 48 V, Battery life (max): 10 year(s). Form factor: Rackmount, Product colour: Black, Silver, Rack capacity: 3U. Certification: CE, EAC
| Features | |
|---|---|
| UPS topology | Double-conversion (Online) |
| Output power capacity | 2.2 |
| Output power | 1980 |
| Waveform | Sine |
| Input operation voltage (min) | 160 |
| Input operation voltage (max) | 275 |
| Input frequency | 40 - 70 |
| Output operation voltage (min) | 220 |
| Output operation voltage (max) | 240 |
| Output frequency | 50/60 |
| Surge energy rating | 432 |
| Crest factor | 3:1 |
| Output voltage Total Harmonic Distortion (THD) | 2 |
| Noise level | 50 |
| Surge protection | Yes |
| Audible alarm(s) | Yes |
| Auto shut-off | Yes |
| Power source type | AC |
| Ports & interfaces | |
| AC outlet types | C13 coupler, C19 coupler |
| AC outlets quantity | 8 |
| Emergency Power Off (EPO) connector | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery voltage | 48 |
| Battery life (max) | 10 |
| Battery recharge time | 4 |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 3U |
| Cable length | 1.83 |
| Product colour | Black, Silver |
| Control type | Buttons |
| Display type | LCD |
| International Protection (IP) code | IP20 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 50 |
| Operating relative humidity (H-H) | 0 - 95 |
| Certificates | |
| Certification | CE, EAC |
| Packaging content | |
| Rack mount kit | Yes |
| Cables included | Output power cable, USB cable |
| Manual | Yes |
| Quick installation guide | Yes |
| Sustainability | |
| Sustainability certificates | Green Premium |
| Weight & dimensions | |
| Width | 432 |
| Depth | 639 |
| Height | 128 |
| Weight | 30.5 |
| Packaging data | |
| Package width | 870 |
| Package depth | 600 |
| Package height | 245 |
| Package weight | 41.4 |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Other features | |
| Bypass | Built-in |
Specifications
| Brand | APC |
