TP-Link BE9300 Whole Home Mesh Wi-Fi 7 System(Tri-Band), White, Internal, Mesh system, 30 dBmW, Tri-band (2.4 GHz / 5 GHz / 6 GHz), Wi-Fi 7 (802.11be)
TP-Link BE9300 Whole Home Mesh Wi-Fi 7 System(Tri-Band). Product colour: White, Antenna type: Internal, Product type: Mesh system. Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz), Top Wi-Fi standard: Wi-Fi 7 (802.11be), WLAN data transfer rate (max): 9300 Mbit/s. Virtual assistant: Amazon Alexa & Google Assistant, Firewall security: SPI, Parental control features: Bedtime, Custom profiles, Family online time ranking, Family time, Off time, Pause the Internet,.... Ethernet LAN data rates: 100,1000,5000 Mbit/s. Power consumption (typical): 29 W, AC input voltage: 100 - 240 V, AC adapter input current: 1 A
| Design | |
|---|---|
| Product type | Mesh system |
| Product colour | White |
| Antenna type | Internal |
| Antennas quantity | 4 |
| Number of devices supported | 200 |
| Transmit power | 30 |
| Reset button | Yes |
| Wireless LAN features | |
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) | 9300 |
| WLAN data transfer rate (first band) | 688 |
| WLAN data transfer rate (second band) | 2882 |
| WLAN data transfer rate (third band) | 5765 |
| Networking standards | IEEE 802.11k, IEEE 802.11r, IEEE 802.11v |
| Security algorithms | WPA-Personal, WPA2-Personal, WPA3-Personal |
| Number of guest networks (5 GHz) | 1 |
| Number of guest networks (2.4 GHz) | 1 |
| Point-to-point protocol over Ethernet (PPPoE) | Yes |
| Dynamic IP | Yes |
| Static IP | Yes |
| IGMP proxy | Yes |
| IGMP snooping | Yes |
| Tagged VLAN | Yes |
| Dynamic DNS (DDNS) | Yes |
| Guest access | Yes |
| Apps supported | TP-Link Deco |
| VPN support | OpenVPN Server, PPTP VPN Server, L2TP/IPSec VPN Server, OpenVPN Client, PPTP VPN Client, L2TP/IPSec VPN Client |
| Features | |
| WPS push button | Yes |
| Virtual assistant | Amazon Alexa & Google Assistant |
| Quality of Service (QoS) support | Yes |
| Port forwarding | Yes |
| Firewall security | SPI |
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Parental control | Yes |
| Parental control features | Bedtime, Custom profiles, Family online time ranking, Family time, Off time, Pause the Internet, Professional content filter library, SafeSearch, Time rewards, Weekly/monthly reports, Youtube restriction |
| Firmware upgradeable via | Network |
| MU-MIMO technology | Yes |
| Operating modes | Router, AP |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 3 |
| Ethernet LAN data rates | 100,1000,5000 |
| Ethernet WAN | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| DC-in jack | Yes |
| Power | |
| Power consumption (typical) | 29 |
| AC input voltage | 100 - 240 |
| AC adapter input current | 1 |
| AC input frequency | 50 - 60 |
| AC adapter output voltage | 12 |
| AC adapter output current | 3.3 |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 60 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Weight & dimensions | |
| Width | 107.5 |
| Depth | 107.5 |
| Height | 176 |
| Packaging content | |
| Number of products included | 2 |
| AC adapter included | Yes |
| Ethernet cable | Yes |
| Quick installation guide | Yes |
| Packaging data | |
| Package width | 241 |
| Package depth | 246 |
| Package height | 118.5 |
| Package weight | 2.47 |
Specifications
| Brand | TP-Link |
| Manufacturer | TP-Link |
