Viewsonic CDE8630, Digital signage flat panel, 2.18 m (86"), LCD, 3840 x 2160 pixels, 24/7
Viewsonic CDE8630. Product design: Digital signage flat panel. Display diagonal: 2.18 m (86"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 450 cd/m², HD type: 4K Ultra HD. Operating hours (hours/days): 24/7. Operating system installed: Android 11. Product colour: Black
| Display | |
|---|---|
| Panel type | ADS |
| LED backlighting type | Direct-LED |
| Display diagonal | 2.18 |
| Display technology | LCD |
| Display resolution | 3840 x 2160 |
| Display brightness | 450 |
| HD type | 4K Ultra HD |
| Touchscreen | No |
| Native aspect ratio | 16:9 |
| Response time | 8 |
| Contrast ratio (typical) | 1200:1 |
| Contrast ratio (dynamic) | 5000:1 |
| Viewing angle, horizontal | 178 |
| Viewing angle, vertical | 178 |
| Display number of colours | 1.07 billion colours |
| Panel life | 50000 |
| Native refresh rate | 60 |
| Haze rate | 25 |
| Surface hardness | 3H |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| HDMI version | 2.0/2.1 |
| HDMI input ports quantity | 2 |
| HDMI output ports quantity | 1 |
| DVI port | No |
| USB port | Yes |
| USB ports quantity | 3 |
| USB version | 2.0/3.2 Gen 1 (3.1 Gen 1) |
| USB connector type | USB Type-A, USB Type-C |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Yes |
| OPS module slot | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of built-in speakers | 2 |
| RMS rated power | 20 |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Orientation | Horizontal/Vertical |
| Product colour | Black |
| Screen shape | Flat |
| VESA mounting | Yes |
| Panel mounting interface | 800 x 400 |
| Bezel width (bottom) | 1.5 |
| Bezel width (side) | 1.5 |
| Bezel width (top) | 1.5 |
| Anti-glare screen | Yes |
| Mounting type | Wall |
| Performance | |
| Purpose | Universal |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Power | |
| Power consumption (typical) | 365 |
| Power consumption (standby) | 0.5 |
| Power consumption (max) | 510 |
| Energy efficiency class (SDR) | G |
| Energy consumption (SDR) per 1000 hours | 318 |
| AC input voltage | 100 - 240 |
| AC input frequency | 50 - 60 |
| Energy efficiency scale | A to G |
| Computer system | |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Built-in processor | Yes |
| Processor frequency | 1.5 |
| Processor cores | 4 |
| Internal memory | 4 |
| On-board graphics card model | ARM Mali-G52 |
| Internal storage capacity | 32 |
| Operating system installed | Android 11 |
| Weight & dimensions | |
| Display width | 1930.8 |
| Display depth | 81.6 |
| Display height | 1101 |
| Display weight | 43.2 |
| Weight | 43.1 |
| Packaging data | |
| Package width | 2110 |
| Package depth | 225 |
| Package height | 1227 |
| Package weight | 60.8 |
| Packaging content | |
| Remote control included | Yes |
| Batteries included | Yes |
| Cables included | AC, HDMI, USB Type-C |
| Mounting kit | Yes |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 20 - 80 |
| Certificates | |
| Certification | cTUus, FCC, Energy Star 8.0, RoHS, Mexico NOM, Mexico Energy |
| Logistics data | |
| Products per master (outer) case | 5 |
| Pallet gross length | 114 |
| Pallet gross width | 2.14 |
| Pallet gross height | 135.6 |
| Harmonized System (HS) code | 8528521000 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 |
| Wi-Fi | No |
| Technical details | |
| OPS slot | 1 |
| Other features | |
| Quick start guide | Yes |
Specifications
| Brand | ViewSonic |
