StarTech.com 10GbE Fiber Ethernet Media Converter for 1/2.5/5/10Gbps Network NBASE-T SFP to RJ45 Multigigabit Singlemode/Multimode Fiber Optic to Copper Network Ethernet to Fiber Bridge~10GbE Fiber Ethernet Media Converter for 10Gbps Network 10GBASE-T SFP to RJ45 Multigigabit Singlemode/Multimode Fiber Optic to Copper Network Ethernet to Fiber Bridge, 10000 Mbit/s, IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an, 10 Gigabit Ethernet, 10,100,1000,1200,2500,5000,10000 Mbit/s, 10GBASE-LR, 10GBASE-SR, Multi-mode, Single-mode
StarTech.com 10GbE Fiber Ethernet Media Converter for 1/2.5/5/10Gbps Network NBASE-T SFP to RJ45 Multigigabit Singlemode/Multimode Fiber Optic to Copper Network Ethernet to Fiber Bridge~10GbE Fiber Ethernet Media Converter for 10Gbps Network 10GBASE-T SFP to RJ45 Multigigabit Singlemode/Multimode Fiber Optic to Copper Network Ethernet to Fiber Bridge. Maximum data transfer rate: 10000 Mbit/s, Networking standards: IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an, Ethernet interface type: 10 Gigabit Ethernet. Fiber mode structure: Multi-mode, Single-mode. LED indicators: Link, Power, Product colour: Black, Housing material: Aluminium. Fiber optic connector: SFP+, Connectivity technology: Wired. Input current: 250 A, Output voltage: 5 V, Output current: 2 A
| Network | |
|---|---|
| Maximum data transfer rate | 10000 |
| Networking standards | IEEE 802.1Q, IEEE 802.3ae, IEEE 802.3an |
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000,1200,2500,5000,10000 |
| Fiber ethernet cabling technology | 10GBASE-LR, 10GBASE-SR |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Performance | |
| Fiber mode structure | Multi-mode, Single-mode |
| Features | |
| Internal | No |
| LED indicators | Link, Power |
| Product colour | Black |
| Housing material | Aluminium |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Fiber optic connector | SFP+ |
| Power | |
| Input current | 250 |
| Output voltage | 5 |
| Output current | 2 |
| Power over Ethernet (PoE) | No |
| External power adapter | Yes |
| Power plug type | Type M |
| Weight & dimensions | |
| Width | 80 |
| Depth | 122 |
| Height | 30 |
| Weight | 274 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 |
| Storage temperature (T-T) | -40 - 120 |
| Operating relative humidity (H-H) | 10 - 90 |
| Packaging content | |
| AC adapter included | Yes |
| Manual | Yes |
| Packaging data | |
| Package width | 144 |
| Package depth | 207 |
| Package height | 38 |
| Package weight | 350 |
| Certificates | |
| Compliance certificates | RoHS |
| Certification | CE, FCC, UL, PSE |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 320 |
| Master (outer) case length | 550 |
| Master (outer) case height | 320 |
| Products per master (outer) case | 20 |
Specifications
| Brand | Startech |
