StarTech.com Rackmount KVM Console HD 1080p - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF, 43.9 cm (17.3"), 1920 x 1080 pixels, TFT LCD, 300 cd/m², 800:1, 170°
StarTech.com Rackmount KVM Console HD 1080p - Single Port VGA KVM with 17" LCD Monitor for Server Rack - Fully Featured 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF. Display diagonal: 43.9 cm (17.3"), Display resolution: 1920 x 1080 pixels, Display: TFT LCD. Video port type: VGA. Certification: CE, FCC, PSE, UL, REACH. Power consumption (typical): 13 W, AC adapter input voltage: 100 - 240 V, Input current: 1.5 A. Width: 483 mm, Height: 565 mm, Depth: 43 mm
| Display | |
|---|---|
| Display diagonal | 43.9 |
| Display resolution | 1920 x 1080 |
| Display | TFT LCD |
| Display brightness | 300 |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 170 |
| Viewing angle, vertical | 170 |
| Pixel pitch | 0.199 x 0.199 |
| Aspect ratio | 16:9 |
| Display type | LCD |
| Display number of colours | 262144 colours |
| Colour depth | 6 |
| Technical details | |
| Material | Steel |
| Mean time between failures (MTBF) | 50000 |
| Product colour | Black |
| Operating relative humidity (H-H) | 10 - 80 |
| Rack mounting | Yes |
| Audio support | No |
| Daisy chain | No |
| IP control | No |
| LED indicators | Power, Status |
| Cable length | 1.8 |
| Compliance certificates | RoHS |
| Rack capacity | 1U |
| Ports & interfaces | |
| Video port type | VGA |
| Keyboard | |
| Built-in touchpad | Yes |
| Certificates | |
| Certification | CE, FCC, PSE, UL, REACH |
| Power | |
| Power consumption (typical) | 13 |
| AC adapter input voltage | 100 - 240 |
| Input current | 1.5 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Weight & dimensions | |
| Width | 483 |
| Height | 565 |
| Depth | 43 |
| Weight | 11.2 |
| Mounting depth (min) | 51 |
| Mounting depth (max) | 85 |
| Packaging data | |
| Package weight | 16 |
| Package width | 615 |
| Package depth | 765 |
| Package height | 185 |
| Packaging content | |
| Cables included | KVM |
| Screws included | Yes |
| Number of screws | 8 |
| Cage nuts included | Yes |
| Number of cage nuts | 8 |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Quick installation guide | Yes |
| Logistics data | |
| Master (outer) case width | 615 |
| Master (outer) case length | 765 |
| Master (outer) case height | 185 |
| Products per master (outer) case | 1 |
Specifications
| Brand | Startech |
