StarTech.com Rackmount KVM Console - Single Port VGA KVM with 19" LCD Monitor for Server Rack - Fully Featured Universal 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF, 48.3 cm (19"), 1280 x 1024 pixels, 250 cd/m², 1000:1, 176°, 170°
StarTech.com Rackmount KVM Console - Single Port VGA KVM with 19" LCD Monitor for Server Rack - Fully Featured Universal 1U LCD KVM Drawer w/Cables & Hardware - USB Support - 50,000 MTBF. Display diagonal: 48.3 cm (19"), Display resolution: 1280 x 1024 pixels, Display brightness: 250 cd/m². Video port type: VGA. Certification: CE, FCC. Power consumption (typical): 17 W. Width: 483 mm, Height: 430 mm, Depth: 533 mm
| Display | |
|---|---|
| Display diagonal | 48.3 |
| Display resolution | 1280 x 1024 |
| Display brightness | 250 |
| Contrast ratio (typical) | 1000:1 |
| Viewing angle, horizontal | 176 |
| Viewing angle, vertical | 170 |
| On Screen Display (OSD) | Yes |
| Pixel pitch | 0.264 x 0.264 |
| Aspect ratio | 4:3 |
| Display type | LCD |
| Display number of colours | 16.78 million colours |
| Technical details | |
| Material | Steel |
| Mean time between failures (MTBF) | 50000 |
| Product colour | Black |
| Operating relative humidity (H-H) | 10 - 80 |
| Audio support | No |
| Daisy chain | Yes |
| Key lock | No |
| IP control | No |
| LED indicators | Yes |
| Compliance certificates | RoHS |
| Rack capacity | 1U |
| Ports & interfaces | |
| Video port type | VGA |
| Keyboard | |
| Built-in touchpad | Yes |
| Hot keys | Yes |
| Certificates | |
| Certification | CE, FCC |
| Power | |
| Power consumption (typical) | 17 |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -20 - 60 |
| Weight & dimensions | |
| Width | 483 |
| Height | 430 |
| Depth | 533 |
| Weight | 12.2 |
| Mounting depth (min) | 50 |
| Mounting depth (max) | 78 |
| Packaging data | |
| Package weight | 16 |
| Package width | 615 |
| Package depth | 765 |
| Package height | 190 |
| Packaging content | |
| Cables included | AC, KVM |
| Screws included | Yes |
| Mounting brackets included | Yes |
| Included power plug types | ANZ, EU, JP, NA, UK |
| Quick installation guide | Yes |
| Logistics data | |
| Master (outer) case width | 615 |
| Master (outer) case length | 765 |
| Master (outer) case height | 190 |
| Products per master (outer) case | 1 |
Specifications
| Brand | Startech |
