TP-Link VIGI C230(2.8mm), IP security camera, Indoor & outdoor, Wired, Ceiling, White, Dome
TP-Link VIGI C230(2.8mm). Type: IP security camera, Placement supported: Indoor & outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Dome. Angle of rotation: 360°, Lens viewing angle, horizontal: 107.5°, Lens viewing angle, vertical: 57.2°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.8 mm (1 / 2.8"). Fixed focal length: 2.8 mm
| Performance | |
|---|---|
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Day/night mode | Yes |
| Design | |
| Form factor | Dome |
| Mounting type | Ceiling |
| Product colour | White |
| Housing material | Plastic |
| International Protection (IP) code | IP67 |
| IK code | IK10 |
| Camera | |
| Camera pan control | Yes |
| Camera tilt control | Yes |
| Minimum illumination | 0 |
| Angle of rotation | 360 |
| Lens viewing angle, horizontal | 107.5 |
| Lens viewing angle, vertical | 57.2 |
| Lens viewing angle, diagonal | 128.7 |
| Tilt angle range | 0 - 85 |
| Pan range | 0 - 360 |
| Image sensor | |
| Optical sensor size | 25.4 / 2.8 |
| Sensor type | CMOS |
| Lens system | |
| Fixed focal length | 2.8 |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 |
| LED type | IR |
| Number of illumination LEDs | 1 |
| Infra-red wavelength | 850 |
| Video | |
| Maximum resolution | 2304 x 1296 |
| Total megapixels | 3 |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 320 x 240, 352 x 288, 640 x 480 (VGA), 704 x 576, 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296 |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Smart IR | Yes |
| Audio | |
| Built-in microphone | Yes |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Wi-Fi | No |
| Bluetooth | No |
| Storage | |
| Built-in HDD | No |
| Security | |
| Password protection | Yes |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Mirror | Yes |
| Password reset via email | Yes |
| Power | |
| Power source type | DC |
| Power consumption (max) | 4.7 |
| DC output voltage | 12 |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 |
| Weight & dimensions | |
| Width | 115 |
| Depth | 86 |
| Height | 115 |
| Packaging content | |
| Number of cameras | 1 |
Specifications
| Brand | TP-Link |
| Manufacturer | TP-Link |
